At NOSTOS, we document the physics of the image. Before the era of fixed pixels (OLED/LCD), the screen was an analog field generated by a high-energy electron stream. The scanline, often misunderstood as a flaw, is actually the architectural backbone of the retro gaming aesthetic.
How the Electron Gun Actually Works
Inside the neck of a CRT are three electron guns, one each for red, green, and blue. Each gun heats a cathode until it releases a stream of electrons. Those electrons are then directed by magnetic deflection yokes, coils of wire wound around the tube neck that bend the beam horizontally and vertically with precision. The entire screen is drawn left-to-right, top-to-bottom, 60 times per second. This is the raster.
The phosphor coating on the inside of the glass reacts to the electron beam by emitting visible light. When the beam passes, the phosphor decays almost instantly, typically within a few microseconds. This near-instantaneous decay is what gives CRT motion its distinctive quality. There is no sample-and-hold artifact, no pixel persistence carrying the previous frame into the current one.
Why 240p Is Architecturally Distinct
Traditional broadcast television (480i) used interlaced scanning. Two alternating fields of 240 lines were drawn per frame, creating the appearance of 480 lines through rapid alternation. If you want the full background on how this signal interacts with display hardware, the 240p signal and retro gaming display guide covers the timing logic in detail.
Retro consoles from the NES through the PlayStation used a timing trick in the vertical blanking interval (VBI) to lock the beam to the same 240 lines every frame, never alternating. This produced a stable, non-interlaced image with consistent gaps between drawn lines. Those gaps are the scanlines. They are not missing data. They are the spaces where the electron beam does not fire, and they give 240p pixel art its characteristic contrast and depth.
Shadow Mask vs. Aperture Grille: What Separates a Consumer TV From a PVM
The way electrons reach the phosphor layer is controlled by a metal mask stretched across the inside of the tube. The type of mask determines the look, brightness, and texture of the image.
Shadow Mask is found in most consumer televisions. It is a perforated metal sheet with millions of small holes arranged in a tricolor dot pattern. The resulting pixel structure is soft and rounded, which works well for broadcast content but softens pixel art edges slightly.
Aperture Grille, used in Sony Trinitron tubes and their professional PVM and BVM variants, replaces the perforated sheet with a series of vertical phosphor stripes separated by thin tensioned wires. The wires are visible as faint horizontal lines near the center and edges of the screen. The vertical-stripe arrangement allows significantly more electrons through, producing a brighter image with sharper vertical scanlines and higher contrast. This is why collectors prioritize Trinitron-based monitors for 16-bit and 32-bit era content.
CRT vs. LCD: A Technical Comparison
| Feature | Modern LCD (1080p/4K) | CRT at 240p |
|---|---|---|
| Pixel Structure | Fixed grid, always active | Dynamic raster, beam-drawn |
| Motion Clarity | Sample-and-hold blur between frames | Instantaneous phosphor decay |
| Scaling | Integer or fractional upscaling, often soft | Native signal, no scaling required |
| Visual Texture | Flat, uniform luminance | Layered scanline depth |
| Black Level | Backlight bleed, elevated blacks | True black between scanlines |
| Pixel Art Rendering | Averaging and softening at low resolution | Pixel edges preserved by raster spacing |
The table above is not a matter of nostalgia. These are measurable, physical differences in how the image is formed. Pixel art from the 16-bit era was designed with the scanline structure in mind. Artists used the dark gaps to suggest shading and detail that the limited palette could not otherwise express.
Phosphor Persistence and Why It Matters for Collectors
Not all CRTs age the same way. Long-term use causes phosphor burn, where frequently lit areas develop reduced brightness relative to surrounding phosphors. On consumer sets used for broadcast, this often appears as a faint ghost of a news ticker or channel logo. On a gaming CRT, it follows the patterns of frequently displayed title screens or health bars.
A healthy phosphor layer produces even luminance across the raster. When evaluating a CRT for purchase, testing with a full-field white signal, then a full-field black signal, reveals burn patterns that are invisible during normal gameplay. Professional-grade PVMs are more resistant to uneven burn due to their higher-quality phosphor formulations, but they are not immune.
