The Vertical Blanking Interval (VBI) is the period in an analog television signal between the end of one frame and the beginning of the next. During this interval, the electron beam of a CRT 'blanks' to move from the bottom-right back to the top-left of the screen. In the 90s archive, this 'dead air' was utilized to transmit digital data, including Closed Captioning (Line 21), Teletext, and vertical interval timecodes (VITC). When a 90s TV was 'under-scanned,' these data streams appeared as flickering white dots and lines at the very top of the visible frame.

Analog Signal Ghosts: Understanding VBI and 90s CRT Data Streams

In the NOSTOS Archive, we document The Invisible Data. Before the internet was the primary pipe for information, the analog television signal was a technical carrier for hidden content. If you’ve ever seen flickering white lines at the top of an old video game or VHS tape, you’ve seen the Vertical Blanking Interval (VBI).

The VBI Architecture

A 90s analog TV signal (NTSC) consists of 525 lines, but only 480 of them carry the actual picture. The remaining 45 lines are the “Blanking Interval.”

The Reset: The electron gun inside your PVM or BVM needs time to physically reset to the top of the glass. During this micro-second “reset,” the signal is technically black.
The Data Hijack: Engineers discovered they could hide digital pulses in these black lines. Line 21 was legally mandated in the US for Closed Captioning data. In Europe, dozens of VBI lines were used for Teletext, a primitive “digital magazine” that provided news and weather before the web existed.

The specific line assignments in NTSC were standardized by the FCC and EIA. Line 21 carried Closed Captioning at 503 bits per second using a biphasic mark coding scheme. Lines 10 through 20 were reserved for other purposes, including Extended Data Services (XDS), which broadcast network identity, program ratings, and time-of-day signals that some VCRs used for automatic clock-setting. The Vertical Interval Timecode (VITC) was embedded on lines 12 through 14, encoding frame-accurate timestamps in the SMPTE format (hours:minutes:seconds:frames) directly into the broadcast signal. Broadcasters used this to synchronize tape machines during live production. In PAL systems (625 lines total), Teletext claimed lines 6 through 22 and 318 through 335, giving European services far more bandwidth, enough to deliver hundreds of “pages” of news, sports scores, and TV schedules delivered in a carousel loop every few seconds.

Finding the Ghosts: Under-scanning

On a standard consumer TV, you couldn’t see the VBI data because the screen was “Over-scanned.” The edges of the signal were pushed past the plastic bezel.

The Archival Look: At NOSTOS, we use professional monitors that allow for “Under-scan” mode. This shrinks the image, revealing the raw edges of the analog broadcast.
The Data Pulse: Under-scanning reveals the “Ghosts” of the 90s: white flickering patterns that look like binary code. This data provides technical timecodes that help our archivists synchronize analog video captures with modern digital frame rates.

Standard consumer overscan on NTSC sets typically hides 5 to 10 percent of the image on each edge. A Sony Trinitron PVM at 14 or 20 inches, configured in “underscan” mode via the service menu, brings the active scan area down to roughly 90 percent of the tube face, exposing the full raster including all 45 blanking lines. On a BVM-series broadcast monitor, underscan is a front-panel toggle. The VBI data itself appears as bright white bursts on lines that are otherwise meant to be held at the blanking level of 0 IRE. The Closed Captioning signal on Line 21 is particularly recognizable: it looks like a short burst of white dots traveling left to right, because it encodes two characters per field at 29.97 fields per second, meaning it must complete a full character-pair encoding cycle within the roughly 63.5-microsecond duration of a single line. VHS recordings of 90s broadcasts that were copied more than two or three generations typically corrupt or drop the Line 21 data entirely, which is one reason NOSTOS values original broadcast recordings over dubs.

Analog vs. Digital Logic

Feature	90s Analog Signal (VBI)	Modern Digital Signal (HDMI)
Data Location	Hidden in the Blanking Interval	Discrete Data Packets
Visual Artifact	Flickering White Lines (Top)	None
Primary Use	Closed Captions / Teletext	Audio / Video / Ethernet
Archival Integrity	Subject to Interference	100% Bit-Perfect
